SlaughterFEM::EqCore< Type > Class Template Reference

A class containing methods for accessing libMesh::Systems This class is meant to be a inherited from other classes; hence, the constructors are all protected. More...

#include <eq_core.h>

Inheritance diagram for SlaughterFEM::EqCore< Type >:

List of all members.

Public Member Functions
string	name ()
	The name of the system.
Type &	get_system ()
	Returns a reference to the system created by this class.
template<typename ParamType >
ParamType	get_constant (string name)
	Template function for extracting heat equation parameter.
template<typename ParamType >
void	set_constant (string name, ParamType var)
	Template function for setting a heat equation parameter.
Protected Member Functions
	EqCore (EquationSystems &sys, string name)
	General class constructor for non-existing systems.
	EqCore (EquationSystems &sys)
	A private constructor for existing systems.
Protected Attributes
EquationSystems &	eq_sys
	A reference to the equation system passed in at construction.
string	name_
	The name of the system created by the class.

---

Detailed Description

template<typename Type>
class SlaughterFEM::EqCore< Type >

A class containing methods for accessing libMesh::Systems This class is meant to be a inherited from other classes; hence, the constructors are all protected.

See also:

EqDataBase

EqVariableLinker

---

Constructor & Destructor Documentation

template<typename Type>

SlaughterFEM::EqCore< Type >::EqCore	(	EquationSystems &	sys,
		string	name
	)		[inline, protected]

General class constructor for non-existing systems.

This constructor takes the system name as an argument, as such it automatically creates the system.

Template Parameters:

Type	The type of libMesh::System (e.g., ExplicitSystem)

Parameters:

sys	libMesh::EquationSystems object that will contain the libMesh::System created
name	A string containing the system name to be created

See also:

EqBaseData

template<typename Type>

SlaughterFEM::EqCore< Type >::EqCore

(

EquationSystems &

sys

)

[inline, protected]

A private constructor for existing systems.

This constructor is useful for inherited classes that extract the use an existing system, as is the case with the EqVariableLinker class.

Template Parameters:

Type	The type of libMesh::System (e.g., ExplicitSystem)

Parameters:

sys	libMesh::EquationSystems object that will contain the libMesh::System created

See also:

EqVariableLinker

---

Member Function Documentation

template<typename Type>

template<typename ParamType >

ParamType SlaughterFEM::EqCore< Type >::get_constant

(

string

name

)

[inline]

Template function for extracting heat equation parameter.

Template Parameters:

ParamType

The type of parameter being extracted (e.g., double)

Parameters:

name	The name of the parameter (e.g., "density")

The primary reason for this is for future expansion to allow for parameters that vary with space and time.

template<typename Type>

Type& SlaughterFEM::EqCore< Type >::get_system

(

)

[inline]

Returns a reference to the system created by this class.

This function simply acts a short-cut for gathering the system that was generated in the class constructor rather than getting it from the supplied EquationSystems object.

Returns:

A reference to the system created by this class

template<typename Type>

string SlaughterFEM::EqCore< Type >::name

(

)

[inline]

The name of the system.

Returns:

The name of the system that the class is linked.

template<typename Type>

template<typename ParamType >

void SlaughterFEM::EqCore< Type >::set_constant	(	string	name,
		ParamType	var
	)		[inline]

Template function for setting a heat equation parameter.

Template Parameters:

ParamType

The type of parameter being added (e.g., double)

Parameters:

name	The name of the parameter (e.g., "density")
var	The value of the parameter (e.g., 123)

The primary reason for this is for future expansion to allow for parameters that vary with space and time.

---

The documentation for this class was generated from the following file:

• include/fem/common/eq_core.h
